Cisco ASA Site-to-Site IKEv1 IPsec VPN


(Oskar N) #21

Here are my ASA Lab files made in VIRL.



asav-1# sh run
: Saved

:
: Serial Number: 9AFCNQ6KLJJ
: Hardware: ASAv, 2048 MB RAM, CPU Pentium II 2201 MHz
:
ASA Version 9.5(1)201
!
hostname asav-1
enable password 2KFQnbNIdI.2KYOU encrypted
xlate per-session deny tcp any4 any4
xlate per-session deny tcp any4 any6
xlate per-session deny tcp any6 any4
xlate per-session deny tcp any6 any6
xlate per-session deny udp any4 any4 eq domain
xlate per-session deny udp any4 any6 eq domain
xlate per-session deny udp any6 any4 eq domain
xlate per-session deny udp any6 any6 eq domain
passwd 2KFQnbNIdI.2KYOU encrypted
names
!
interface GigabitEthernet0/0
description to iosv-1
duplex full
nameif inside
security-level 100
ip address 192.168.1.254 255.255.255.0
!
interface GigabitEthernet0/1
description to asav-2
duplex full
nameif outside-1
security-level 0
ip address 10.10.10.1 255.255.255.0
!
interface Management0/0
description OOB Management
duplex full
management-only
nameif mgmt
security-level 100
ip address 10.255.0.124 255.255.0.0
!
ftp mode passive
same-security-traffic permit inter-interface
access-list lan-to-lan extended permit ip 192.168.1.0 255.255.255.0 192.168.2.0 255.255.255.0
pager lines 23
logging enable
logging asdm informational
mtu inside 1500
mtu outside-1 1500
mtu mgmt 1500
no failover
icmp unreachable rate-limit 1 burst-size 1
no asdm history enable
arp timeout 14400
no arp permit-nonconnected
route outside-1 192.168.2.0 255.255.255.0 10.10.10.2 1
timeout xlate 3:00:00
timeout pat-xlate 0:00:30
timeout conn 1:00:00 half-closed 0:10:00 udp 0:02:00 icmp 0:00:02
timeout sunrpc 0:10:00 h323 0:05:00 h225 1:00:00 mgcp 0:05:00 mgcp-pat 0:05:00
timeout sip 0:30:00 sip_media 0:02:00 sip-invite 0:03:00 sip-disconnect 0:02:00
timeout sip-provisional-media 0:02:00 uauth 0:05:00 absolute
timeout tcp-proxy-reassembly 0:01:00
timeout floating-conn 0:00:00
user-identity default-domain LOCAL
aaa authentication ssh console LOCAL
http server enable
http 0.0.0.0 0.0.0.0 mgmt
http 0.0.0.0 0.0.0.0 inside
http 0.0.0.0 0.0.0.0 outside-1
no snmp-server location
no snmp-server contact
crypto ipsec ikev1 transform-set mytransform esp-3des esp-sha-hmac
crypto ipsec security-association pmtu-aging infinite
crypto map mycrypto 10 match address lan-to-lan
crypto map mycrypto 10 set peer 10.10.10.2
crypto map mycrypto 10 set ikev1 transform-set mytransform
crypto map mycrypto 10 set security-association lifetime seconds 3600
crypto map mycrypto interface outside-1
crypto ca trustpoint _SmartCallHome_ServerCA
no validation-usage
crl configure
crypto ca trustpool policy
crypto ca certificate chain _SmartCallHome_ServerCA
certificate ca 6ecc7aa5a7032009b8cebcf4e952d491
308205ec 308204d4 a0030201 0202106e cc7aa5a7 032009b8 cebcf4e9 52d49130
0d06092a 864886f7 0d010105 05003081 ca310b30 09060355 04061302 55533117
30150603 55040a13 0e566572 69536967 6e2c2049 6e632e31 1f301d06 0355040b
13165665 72695369 676e2054 72757374 204e6574 776f726b 313a3038 06035504
0b133128 63292032 30303620 56657269 5369676e 2c20496e 632e202d 20466f72
20617574 686f7269 7a656420 75736520 6f6e6c79 31453043 06035504 03133c56
65726953 69676e20 436c6173 73203320 5075626c 69632050 72696d61 72792043
65727469 66696361 74696f6e 20417574 686f7269 7479202d 20473530 1e170d31
30303230 38303030 3030305a 170d3230 30323037 32333539 35395a30 81b5310b
30090603 55040613 02555331 17301506 0355040a 130e5665 72695369 676e2c20
496e632e 311f301d 06035504 0b131656 65726953 69676e20 54727573 74204e65
74776f72 6b313b30 39060355 040b1332 5465726d 73206f66 20757365 20617420
68747470 733a2f2f 7777772e 76657269 7369676e 2e636f6d 2f727061 20286329
3130312f 302d0603 55040313 26566572 69536967 6e20436c 61737320 33205365
63757265 20536572 76657220 4341202d 20473330 82012230 0d06092a 864886f7
0d010101 05000382 010f0030 82010a02 82010100 b187841f c20c45f5 bcab2597
a7ada23e 9cbaf6c1 39b88bca c2ac56c6 e5bb658e 444f4dce 6fed094a d4af4e10
9c688b2e 957b899b 13cae234 34c1f35b f3497b62 83488174 d188786c 0253f9bc
7f432657 5833833b 330a17b0 d04e9124 ad867d64 12dc744a 34a11d0a ea961d0b
15fca34b 3bce6388 d0f82d0c 948610ca b69a3dca eb379c00 48358629 5078e845
63cd1941 4ff595ec 7b98d4c4 71b350be 28b38fa0 b9539cf5 ca2c23a9 fd1406e8
18b49ae8 3c6e81fd e4cd3536 b351d369 ec12ba56 6e6f9b57 c58b14e7 0ec79ced
4a546ac9 4dc5bf11 b1ae1c67 81cb4455 33997f24 9b3f5345 7f861af3 3cfa6d7f
81f5b84a d3f58537 1cb5a6d0 09e4187b 384efa0f 02030100 01a38201 df308201
db303406 082b0601 05050701 01042830 26302406 082b0601 05050730 01861868
7474703a 2f2f6f63 73702e76 65726973 69676e2e 636f6d30 12060355 1d130101
ff040830 060101ff 02010030 70060355 1d200469 30673065 060b6086 480186f8
45010717 03305630 2806082b 06010505 07020116 1c687474 70733a2f 2f777777
2e766572 69736967 6e2e636f 6d2f6370 73302a06 082b0601 05050702 02301e1a
1c687474 70733a2f 2f777777 2e766572 69736967 6e2e636f 6d2f7270 61303406
03551d1f 042d302b 3029a027 a0258623 68747470 3a2f2f63 726c2e76 65726973
69676e2e 636f6d2f 70636133 2d67352e 63726c30 0e060355 1d0f0101 ff040403
02010630 6d06082b 06010505 07010c04 61305fa1 5da05b30 59305730 55160969
6d616765 2f676966 3021301f 30070605 2b0e0302 1a04148f e5d31a86 ac8d8e6b
c3cf806a d448182c 7b192e30 25162368 7474703a 2f2f6c6f 676f2e76 65726973
69676e2e 636f6d2f 76736c6f 676f2e67 69663028 0603551d 11042130 1fa41d30
1b311930 17060355 04031310 56657269 5369676e 4d504b49 2d322d36 301d0603
551d0e04 1604140d 445c1653 44c1827e 1d20ab25 f40163d8 be79a530 1f060355
1d230418 30168014 7fd365a7 c2ddecbb f03009f3 4339fa02 af333133 300d0609
2a864886 f70d0101 05050003 82010100 0c8324ef ddc30cd9 589cfe36 b6eb8a80
4bd1a3f7 9df3cc53 ef829ea3 a1e697c1 589d756c e01d1b4c fad1c12d 05c0ea6e
b2227055 d9203340 3307c265 83fa8f43 379bea0e 9a6c70ee f69c803b d937f47a
6decd018 7d494aca 99c71928 a2bed877 24f78526 866d8705 404167d1 273aeddc
481d22cd 0b0b8bbc f4b17bfd b499a8e9 762ae11a 2d876e74 d388dd1e 22c6df16
b62b8214 0a945cf2 50ecafce ff62370d ad65d306 4153ed02 14c8b558 28a1ace0
5becb37f 954afb03 c8ad26db e6667812 4ad99f42 fbe198e6 42839b8f 8f6724e8
6119b5dd cdb50b26 058ec36e c4c875b8 46cfe218 065ea9ae a8819a47 16de0c28
6c2527b9 deb78458 c61f381e a4c4cb66
quit
crypto ikev1 policy 10
authentication pre-share
encryption aes
hash sha
group 2
lifetime 3600
telnet 0.0.0.0 0.0.0.0 inside
telnet 0.0.0.0 0.0.0.0 outside-1
telnet 0.0.0.0 0.0.0.0 mgmt
telnet timeout 15
ssh stricthostkeycheck
ssh 0.0.0.0 0.0.0.0 inside
ssh 0.0.0.0 0.0.0.0 outside-1
ssh 0.0.0.0 0.0.0.0 mgmt
ssh timeout 5
ssh version 2
ssh key-exchange group dh-group1-sha1
console timeout 0
threat-detection basic-threat
threat-detection statistics access-list
no threat-detection statistics tcp-intercept
dynamic-access-policy-record DfltAccessPolicy
username cisco password 3USUcOPFUiMCO4Jk encrypted privilege 15
tunnel-group 10.10.10.2 type ipsec-l2l
tunnel-group 10.10.10.2 ipsec-attributes
ikev1 pre-shared-key *****
!
class-map inspection_default
match default-inspection-traffic
!
!
policy-map type inspect dns preset_dns_map
parameters
message-length maximum client auto
message-length maximum 512
policy-map global_policy
class inspection_default
inspect ip-options
inspect netbios
inspect rtsp
inspect sunrpc
inspect tftp
inspect xdmcp
inspect icmp
inspect http
inspect dns preset_dns_map
inspect ftp
inspect h323 h225
inspect h323 ras
inspect rsh
inspect esmtp
inspect sqlnet
inspect sip
inspect skinny
policy-map type inspect dns migrated_dns_map_1
parameters
message-length maximum client auto
message-length maximum 512
!
service-policy global_policy global
prompt hostname context
no call-home reporting anonymous
call-home
profile CiscoTAC-1
no active
destination address http https://tools.cisco.com/its/service/oddce/services/DDCEService
destination address email callhome@cisco.com
profile License
destination address http https://tools.cisco.com/its/service/oddce/services/DDCEService
destination transport-method http
Cryptochecksum:1b43ef16ea9f95af6ee063b46a10a00b
: end

-

asav-2# sh run
: Saved

:
: Serial Number: 9A7SE7UJDQS
: Hardware: ASAv, 2048 MB RAM, CPU Pentium II 2201 MHz
:
ASA Version 9.5(1)201
!
hostname asav-2
enable password 2KFQnbNIdI.2KYOU encrypted
xlate per-session deny tcp any4 any4
xlate per-session deny tcp any4 any6
xlate per-session deny tcp any6 any4
xlate per-session deny tcp any6 any6
xlate per-session deny udp any4 any4 eq domain
xlate per-session deny udp any4 any6 eq domain
xlate per-session deny udp any6 any4 eq domain
xlate per-session deny udp any6 any6 eq domain
passwd 2KFQnbNIdI.2KYOU encrypted
names
!
interface GigabitEthernet0/0
description to iosv-2
duplex full
nameif inside
security-level 100
ip address 192.168.2.254 255.255.255.0
!
interface GigabitEthernet0/1
description to asav-1
duplex full
nameif outside
security-level 0
ip address 10.10.10.2 255.255.255.0
!
interface Management0/0
description OOB Management
duplex full
management-only
nameif mgmt
security-level 100
ip address 10.255.0.123 255.255.0.0
!
ftp mode passive
same-security-traffic permit inter-interface
access-list lan-to-lan extended permit ip 192.168.2.0 255.255.255.0 192.168.1.0 255.255.255.0
pager lines 23
logging enable
logging asdm informational
mtu inside 1500
mtu outside 1500
mtu mgmt 1500
no failover
icmp unreachable rate-limit 1 burst-size 1
no asdm history enable
arp timeout 14400
no arp permit-nonconnected
route outside 192.168.1.0 255.255.255.0 10.10.10.1 1
timeout xlate 3:00:00
timeout pat-xlate 0:00:30
timeout conn 1:00:00 half-closed 0:10:00 udp 0:02:00 icmp 0:00:02
timeout sunrpc 0:10:00 h323 0:05:00 h225 1:00:00 mgcp 0:05:00 mgcp-pat 0:05:00
timeout sip 0:30:00 sip_media 0:02:00 sip-invite 0:03:00 sip-disconnect 0:02:00
timeout sip-provisional-media 0:02:00 uauth 0:05:00 absolute
timeout tcp-proxy-reassembly 0:01:00
timeout floating-conn 0:00:00
user-identity default-domain LOCAL
aaa authentication ssh console LOCAL
http server enable
http 0.0.0.0 0.0.0.0 mgmt
http 0.0.0.0 0.0.0.0 inside
http 0.0.0.0 0.0.0.0 outside
no snmp-server location
no snmp-server contact
crypto ipsec ikev1 transform-set mytransform esp-3des esp-sha-hmac
crypto ipsec security-association pmtu-aging infinite
crypto map mycrypto 10 match address lan-to-lan
crypto map mycrypto 10 set peer 10.10.10.1
crypto map mycrypto 10 set ikev1 transform-set mytransform
crypto map mycrypto 10 set security-association lifetime seconds 3600
crypto map mycrypto interface outside
crypto ca trustpoint _SmartCallHome_ServerCA
no validation-usage
crl configure
crypto ca trustpool policy
crypto ca certificate chain _SmartCallHome_ServerCA
certificate ca 6ecc7aa5a7032009b8cebcf4e952d491
308205ec 308204d4 a0030201 0202106e cc7aa5a7 032009b8 cebcf4e9 52d49130
0d06092a 864886f7 0d010105 05003081 ca310b30 09060355 04061302 55533117
30150603 55040a13 0e566572 69536967 6e2c2049 6e632e31 1f301d06 0355040b
13165665 72695369 676e2054 72757374 204e6574 776f726b 313a3038 06035504
0b133128 63292032 30303620 56657269 5369676e 2c20496e 632e202d 20466f72
20617574 686f7269 7a656420 75736520 6f6e6c79 31453043 06035504 03133c56
65726953 69676e20 436c6173 73203320 5075626c 69632050 72696d61 72792043
65727469 66696361 74696f6e 20417574 686f7269 7479202d 20473530 1e170d31
30303230 38303030 3030305a 170d3230 30323037 32333539 35395a30 81b5310b
30090603 55040613 02555331 17301506 0355040a 130e5665 72695369 676e2c20
496e632e 311f301d 06035504 0b131656 65726953 69676e20 54727573 74204e65
74776f72 6b313b30 39060355 040b1332 5465726d 73206f66 20757365 20617420
68747470 733a2f2f 7777772e 76657269 7369676e 2e636f6d 2f727061 20286329
3130312f 302d0603 55040313 26566572 69536967 6e20436c 61737320 33205365
63757265 20536572 76657220 4341202d 20473330 82012230 0d06092a 864886f7
0d010101 05000382 010f0030 82010a02 82010100 b187841f c20c45f5 bcab2597
a7ada23e 9cbaf6c1 39b88bca c2ac56c6 e5bb658e 444f4dce 6fed094a d4af4e10
9c688b2e 957b899b 13cae234 34c1f35b f3497b62 83488174 d188786c 0253f9bc
7f432657 5833833b 330a17b0 d04e9124 ad867d64 12dc744a 34a11d0a ea961d0b
15fca34b 3bce6388 d0f82d0c 948610ca b69a3dca eb379c00 48358629 5078e845
63cd1941 4ff595ec 7b98d4c4 71b350be 28b38fa0 b9539cf5 ca2c23a9 fd1406e8
18b49ae8 3c6e81fd e4cd3536 b351d369 ec12ba56 6e6f9b57 c58b14e7 0ec79ced
4a546ac9 4dc5bf11 b1ae1c67 81cb4455 33997f24 9b3f5345 7f861af3 3cfa6d7f
81f5b84a d3f58537 1cb5a6d0 09e4187b 384efa0f 02030100 01a38201 df308201
db303406 082b0601 05050701 01042830 26302406 082b0601 05050730 01861868
7474703a 2f2f6f63 73702e76 65726973 69676e2e 636f6d30 12060355 1d130101
ff040830 060101ff 02010030 70060355 1d200469 30673065 060b6086 480186f8
45010717 03305630 2806082b 06010505 07020116 1c687474 70733a2f 2f777777
2e766572 69736967 6e2e636f 6d2f6370 73302a06 082b0601 05050702 02301e1a
1c687474 70733a2f 2f777777 2e766572 69736967 6e2e636f 6d2f7270 61303406
03551d1f 042d302b 3029a027 a0258623 68747470 3a2f2f63 726c2e76 65726973
69676e2e 636f6d2f 70636133 2d67352e 63726c30 0e060355 1d0f0101 ff040403
02010630 6d06082b 06010505 07010c04 61305fa1 5da05b30 59305730 55160969
6d616765 2f676966 3021301f 30070605 2b0e0302 1a04148f e5d31a86 ac8d8e6b
c3cf806a d448182c 7b192e30 25162368 7474703a 2f2f6c6f 676f2e76 65726973
69676e2e 636f6d2f 76736c6f 676f2e67 69663028 0603551d 11042130 1fa41d30
1b311930 17060355 04031310 56657269 5369676e 4d504b49 2d322d36 301d0603
551d0e04 1604140d 445c1653 44c1827e 1d20ab25 f40163d8 be79a530 1f060355
1d230418 30168014 7fd365a7 c2ddecbb f03009f3 4339fa02 af333133 300d0609
2a864886 f70d0101 05050003 82010100 0c8324ef ddc30cd9 589cfe36 b6eb8a80
4bd1a3f7 9df3cc53 ef829ea3 a1e697c1 589d756c e01d1b4c fad1c12d 05c0ea6e
b2227055 d9203340 3307c265 83fa8f43 379bea0e 9a6c70ee f69c803b d937f47a
6decd018 7d494aca 99c71928 a2bed877 24f78526 866d8705 404167d1 273aeddc
481d22cd 0b0b8bbc f4b17bfd b499a8e9 762ae11a 2d876e74 d388dd1e 22c6df16
b62b8214 0a945cf2 50ecafce ff62370d ad65d306 4153ed02 14c8b558 28a1ace0
5becb37f 954afb03 c8ad26db e6667812 4ad99f42 fbe198e6 42839b8f 8f6724e8
6119b5dd cdb50b26 058ec36e c4c875b8 46cfe218 065ea9ae a8819a47 16de0c28
6c2527b9 deb78458 c61f381e a4c4cb66
quit
crypto ikev1 enable outside
crypto ikev1 policy 10
authentication pre-share
encryption aes
hash sha
group 2
lifetime 3600
telnet 0.0.0.0 0.0.0.0 inside
telnet 0.0.0.0 0.0.0.0 outside
telnet 0.0.0.0 0.0.0.0 mgmt
telnet timeout 15
ssh stricthostkeycheck
ssh 0.0.0.0 0.0.0.0 inside
ssh 0.0.0.0 0.0.0.0 outside
ssh 0.0.0.0 0.0.0.0 mgmt
ssh timeout 5
ssh version 2
ssh key-exchange group dh-group1-sha1
console timeout 0
threat-detection basic-threat
threat-detection statistics access-list
no threat-detection statistics tcp-intercept
dynamic-access-policy-record DfltAccessPolicy
username cisco password 3USUcOPFUiMCO4Jk encrypted privilege 15
tunnel-group 10.10.10.1 type ipsec-l2l
tunnel-group 10.10.10.1 ipsec-attributes
ikev1 pre-shared-key *****
!
class-map inspection_default
match default-inspection-traffic
!
!
policy-map type inspect dns preset_dns_map
parameters
message-length maximum client auto
message-length maximum 512
policy-map global_policy
class inspection_default
inspect ip-options
inspect netbios
inspect rtsp
inspect sunrpc
inspect tftp
inspect xdmcp
inspect icmp
inspect http
inspect dns preset_dns_map
inspect ftp
inspect h323 h225
inspect h323 ras
inspect rsh
inspect esmtp
inspect sqlnet
inspect sip
inspect skinny
policy-map type inspect dns migrated_dns_map_1
parameters
message-length maximum client auto
message-length maximum 512
!
service-policy global_policy global
prompt hostname context
no call-home reporting anonymous
call-home
profile CiscoTAC-1
no active
destination address http https://tools.cisco.com/its/service/oddce/services/DDCEService
destination address email callhome@cisco.com
profile License
destination address http https://tools.cisco.com/its/service/oddce/services/DDCEService
destination transport-method http
Cryptochecksum:14a7ca747e6eb8a1e7ae9c8756c87c29
: end
asav-2#

(Rene Molenaar) #22

Hi Oskar,

Couple of things I did:

  1. If you scroll to the bottom of the lesson, you can now find my ASA + router configuration files.
  2. I added my VIRL file as an attachment here.
  3. Found two errors in your files:
    1. You didn't add the crypto isakmp identity address command.
    2. You didn't add the crypto ikev1 enable OUTSIDE command.


Hope this helps.

Rene

asa_ipsec_site_to_site_ikev1.zip (4.8 KB)


(Oskar N) #23

Hi

i lab it up in a hurry so i can put it in …but i want to do it in GNS3 for some reason dispite i have generate a flash i cant save the config.




(Rene Molenaar) #24

Hi Oskar,

For GNS3 related issues it’s best to check the GNS3.com forums, I never really used the ASA in Qemu…always had issues with it.

Rene


(Rene Molenaar) #25

Hi Amin,

I attached all your config files in one post. I checked your configs, they are looking good to me. If you ping or telnet from R1 to R2 (or vice versa) then nothing happens?

Are you sure this is not some GNS3 / Qemu quirk?

Rene


(Syed A) #26

Hi Rene,

Yes, ping between R1 and R2 fails. Thanks for looking into the problem. If my configs look good to you, then it must be a GNS issue. At least now I know that there’s nothing wrong with my configuration.

I’ll have to wait until I get access to real equipment in order to test my configuration.

Thanks again for your help.

Regards, Amin


(Oskar N) #27

HI

I will lab it up today, been working and training so not that much time.




(Oskar N) #28

Hi !

I lab it up in GNS3 it doesnt work and i am getting tired not able to save it.

So i will do it int Cisco VRIL…


(Rene Molenaar) #29

Hi Oskar,

Sounds like a good idea, the ASAv image works like a charm.

Rene


(Rene Molenaar) #30

Hi Amin,

You can also try the ASAv image in vmware ESXi (workstation might work too). That works great.

Rene


(Oskar N) #31

I will all your labs in virl , i had a problem the labs disappeard , contacted the virl community but have not got any answer.


(Oskar N) #32

Hi guys !

I give up nothing works GNS3 cant save config, and in VIRL my workspace disappear ??? i am using vm Workstation …so anybody knows ?

i will give a last try …i will go to DMvpn for my ccnp security later on…:slight_smile:



/Oskar


(Syed A) #33

Hi Rene,

Thanks for letting me know about ASAv. I’ll find out if they have a workstation version. If so, I’ll try to set up that environment on my PC, and see how that works.

Thanks again, Amin


(Rene Molenaar) #34

Hi Oskar,

Hmm what exactly do you mean that your workspace dissapears in Virl? I never had any issues with it so far.

Rene


(Mark) #35

Hi Rene,

I have some problem for asa ipsec vpn and nat integration. please see my network design. pc1 connect to pc2 with VPN ipsec tunnel and then pc1 connect to router 3 loopback interface 200.200.200.0 network with NAT. Now pc1 and pc2 tunnel is ok but asa can’t translate NAT address for pc1 and pc1 can’t go to router 3 (network 200.200.200.0/24). I would like to know, could I able to use NAT and VPN for one local network.


(Rene Molenaar) #36

Hi Mark,

It sounds like your ASA isn’t configured correctly for NAT. It should be configured to translate all traffic from the 192.168.2.0/24 subnet that exits the outside interface UNLESS the destination is 192.168.39.0/24 (the other end of the VPN).

You can use this example for PAT:

Cisco ASA PAT configuration

The only thing left to do is to create an exception for your VPN traffic, like this:

object network LOCAL_SUBNET
 subnet 192.168.2.0 255.255.255.0

 object network REMOTE_SUBNET
 subnet 192.168.39.0 255.255.255.0

nat (LOCAL_SUBNET,OUTSIDE) source static LOCAL_SUBNET LOCAL_SUBNET destination static REMOTE_SUBNET REMOTE_SUBNET

This tells the ASA not to translate traffic from the local to the remote subnet.

If you are also doing NAT on R2 then you’ll need to add a deny statement in the access-list that you use for NAT that matches traffic between 192.168.39.0/24 and 192.168.2.0/24.

Hope this helps!

Rene


IPSEC Tunnel Phase 2 Traffic is not encrypted
(Mohammad Hasanuz Zaman) #37

Hi Rene,

As per your IPsec lesson…The IPsec (ESP,AH)protocols support two different modes:

1.Transport mode
2.Tunnel mode

So, How we will define that IPsec ESP/AH will use either Transport or Tunnel mode and what is the default mode ??

And also IKEV1 phase-1 tunnel can be completed using two different modes:

1.Main mode
2.Aggressive mode

where we will define that will use either Aggressive or Main mode ??

Could you please explain a little bit .Thx

br//
zaman


(Mohammad Hasanuz Zaman) #38

Hi Rene,

What is the difference between below two commands? Please give some more clarification on it.Thanks

ASA2(config-ikev1-policy)# lifetime 3600

ASA2(config)# crypto map MY_CRYPTO_MAP 10 set security-association lifetime seconds 3600

br//
zaman


(Networklessons Admin) split this topic #39

19 posts were merged into an existing topic: Cisco ASA Site-to-Site IKEv1 IPsec VPN


(Rene Molenaar) #40

Hi Zaman,

Aggressive mode can be configured in the crypto map:

ASA1(config)# crypto map MY_CRYPTO_MAP 10 set ikev1 phase1-mode aggressive

And transport mode in the transform set:

ASA1(config)# crypto ipsec ikev1 transform-set MY_TRANSFORM_SET mode ?

configure mode commands/options:
  transport  mode transport

The first lifetime (ikev1 policy) is for phase 1 and the lifetime in the crypto map is for phase 2.

Rene
