IPv6 over IPv4 GRE with IPSec

(Rene Molenaar) #1

This topic is to discuss the following lesson:

0 Likes

(Chris N) #2

Quick question Rene, if you were to omit the IPv6 global unicast address on the tunnel interface, would you need to use “ipv6 enable” instead so OSPFv3 could use a link local address? Or does enabling OSPFv3 on the interface automatically generate a link local address?

0 Likes

(Rene Molenaar) #3

Hi Chris,

You’ll need to configure an IPv6 address or use “ipv6 enable”. Without an address, you get an error:

R1(config)#interface GigabitEthernet 0/1
R1(config-if)#ipv6 ospf 1 area 0
% OSPFv3: IPV6 is not enabled on this interface

Rene

1 Like

(Fabrice M) #4

Hi Rene
I use virtual tunnel interface and i seem to work, it is correct ?

IPv4 Crypto ISAKMP SA
dst             src             state          conn-id status
192.168.12.2    192.168.12.1    QM_IDLE           1002 ACTIVE
192.168.12.1    192.168.12.2    QM_IDLE           1001 ACTIVE

IPv6 Crypto ISAKMP SA

R1#sh crypto ipsec sa

interface: Tunnel0
    Crypto map tag: Tunnel0-head-0, local addr 192.168.12.1

   protected vrf: (none)
   local  ident (addr/mask/prot/port): (192.168.12.1/255.255.255.255/47/0)
   remote ident (addr/mask/prot/port): (192.168.12.2/255.255.255.255/47/0)
   current_peer 192.168.12.2 port 500
     PERMIT, flags={origin_is_acl,}
    #pkts encaps: 256, #pkts encrypt: 256, #pkts digest: 256
    #pkts decaps: 245, #pkts decrypt: 245, #pkts verify: 245
    #pkts compressed: 0, #pkts decompressed: 0
    #pkts not compressed: 0, #pkts compr. failed: 0

Another question is how much mtu does IPsec Takes

Cordially

0 Likes

(Rene Molenaar) #5

Hi Fabrice,

This is looking good, the number of packets encrypted/decrypted tells you your VPN is working.

The overhead of IPSec depends whether you use AH, ESP, AH+ESP, tunnel or transport mode, and the algorithms you use. Cisco has a very nice calculator that shows you exactly how much overhead you’ll have. Here is a screenshot:

Rene

0 Likes
