Leaking specific BGP routes

Routing & Switching BGP
1

I apologize if this question is naive, but how can leaking specific routes influence incoming BGP traffic?

2

Hello @jbhosle ,

Not naive at all. With some networking concepts, it can be difficult to wrap your head around it. Here is an example.

Imagine we have three routers: R1, R2, and R3. Connected in a triangle. Each router has its own AS. R1 has a loopback interface with 1.1.1.1/32, which we advertise as a 1.0.0.0/8 summary route.

Here are the configs:

hostname R1
!
interface Loopback0
 ip address 1.1.1.1 255.255.255.255
!
interface GigabitEthernet0/0
 ip address 192.168.12.1 255.255.255.0
!
interface GigabitEthernet0/1
 ip address 192.168.13.1 255.255.255.0
!
router bgp 1
 bgp router-id 1.1.1.1
 network 1.1.1.1 mask 255.255.255.255
 aggregate-address 1.0.0.0 255.0.0.0 summary-only
 neighbor 192.168.12.2 remote-as 2
 neighbor 192.168.13.3 remote-as 3
!
end
hostname R2
!
interface GigabitEthernet0/0
 ip address 192.168.12.2 255.255.255.0
!
interface GigabitEthernet0/1
 ip address 192.168.23.2 255.255.255.0
!
router bgp 2
 bgp router-id 2.2.2.2
 neighbor 192.168.12.1 remote-as 1
 neighbor 192.168.23.3 remote-as 3
!
end
hostname R3
!
interface GigabitEthernet0/0
 ip address 192.168.13.3 255.255.255.0
!
interface GigabitEthernet0/1
 ip address 192.168.23.3 255.255.255.0
!
router bgp 3
 bgp router-id 3.3.3.3
 neighbor 192.168.13.1 remote-as 1
 neighbor 192.168.23.2 remote-as 2
!
end

Here is the BGP table of R2 and R3:

R2#show ip bgp
BGP table version is 5, local router ID is 2.2.2.2
Status codes: s suppressed, d damped, h history, * valid, > best, i - internal,
              r RIB-failure, S Stale, m multipath, b backup-path, f RT-Filter,
              x best-external, a additional-path, c RIB-compressed,
              t secondary path,
Origin codes: i - IGP, e - EGP, ? - incomplete
RPKI validation codes: V valid, I invalid, N Not found

     Network          Next Hop            Metric LocPrf Weight Path
 *    1.0.0.0          192.168.23.3                           0 3 1 i
 *>                    192.168.12.1             0             0 1 i
R3#show ip bgp
BGP table version is 5, local router ID is 3.3.3.3
Status codes: s suppressed, d damped, h history, * valid, > best, i - internal,
              r RIB-failure, S Stale, m multipath, b backup-path, f RT-Filter,
              x best-external, a additional-path, c RIB-compressed,
              t secondary path,
Origin codes: i - IGP, e - EGP, ? - incomplete
RPKI validation codes: V valid, I invalid, N Not found

     Network          Next Hop            Metric LocPrf Weight Path
 *    1.0.0.0          192.168.23.2                           0 2 1 i
 *>                    192.168.13.1             0             0 1 i

As you can see, R2 and R3 both use their link to R1 to reach 1.1.1.1.

Now let’s make a change on R1:

R1(config)#route-map ADVERTISE_SPECIFIC_L0 permit 10
R1(config-route-map)#match ip address R1_L0

R1(config)#ip access-list standard R1_L0
R1(config-std-nacl)#permit host 1.1.1.1

R1(config)#router bgp 1
R1(config-router)#neighbor 192.168.12.2 unsuppress-map ADVERTISE_SPECIFIC_L0

This tells R1 to advertise the specific route 1.1.1.1/32 to R2, next to the summary route.

Clear the BGP neighbor adjacency or do a soft reconfiguration:

R1# clear ip bgp * soft

Now look at R2 and R3 again:

R2#show ip bgp
BGP table version is 6, local router ID is 2.2.2.2
Status codes: s suppressed, d damped, h history, * valid, > best, i - internal,
              r RIB-failure, S Stale, m multipath, b backup-path, f RT-Filter,
              x best-external, a additional-path, c RIB-compressed,
              t secondary path,
Origin codes: i - IGP, e - EGP, ? - incomplete
RPKI validation codes: V valid, I invalid, N Not found

     Network          Next Hop            Metric LocPrf Weight Path
 *    1.0.0.0          192.168.23.3                           0 3 1 i
 *>                    192.168.12.1             0             0 1 i
 *>   1.1.1.1/32       192.168.12.1             0             0 1 i

R2 receives the summary route and the specific 1.1.1.1/32 prefix. All is good. Here is R3:

R3#show ip bgp
BGP table version is 6, local router ID is 3.3.3.3
Status codes: s suppressed, d damped, h history, * valid, > best, i - internal,
              r RIB-failure, S Stale, m multipath, b backup-path, f RT-Filter,
              x best-external, a additional-path, c RIB-compressed,
              t secondary path,
Origin codes: i - IGP, e - EGP, ? - incomplete
RPKI validation codes: V valid, I invalid, N Not found

     Network          Next Hop            Metric LocPrf Weight Path
 *    1.0.0.0          192.168.23.2                           0 2 1 i
 *>                    192.168.13.1             0             0 1 i
 *>   1.1.1.1/32       192.168.23.2                           0 2 1 i

This is not good. R3 uses R2 to get to 1.1.1.1 because this is a more specific route. R2 “leaks” that specific route to R3. Now imagine R3 belongs to a huge ISP and R2 is some small company…

I hope this helps!

Rene

3

Hi @jbhosle ,

Here is a detailed lesson explaining BGP route leaking:

Rene
