PPP Multilink Link Fragmentation and Interleaving

(Rene Molenaar) #1

This topic is to discuss the following lesson:

0 Likes

(Abdelaziz Mahmoud H) #2

An awesome topic I was looking for. Simple and easy to understand. Thank you Rene

0 Likes

(Joseph H) #3

Rene,
Don’t you need a group command to bundle the interfaces together? That’s what I have used:

interface Multilink1
ip address <ENTER WAN IP HERE (CER)>
ppp multilink
ppp multilink group 1

interface Serial0
no ip address
encapsulation ppp
ppp multilink
ppp multilink group 1

interface Serial1
no ip address
encapsulation ppp
ppp multilink
ppp multilink group 1

0 Likes

(Fulvio F) #5

Hi… I think that only if you will use more than one interface in our MultLink interface. In the Lesson… Rene use one interface.

0 Likes

(Rene Molenaar) #6

Here’s an example where I used the multilink group:

It’s a clean example of two interfaces that are bundled in a multilink, without link fragmentation / interleaving.

1 Like
